FC4 Series Observation Thermal Bullet Camera
Views: 539
$0.00
- FC4A thermal bullet camera equipped a 640×512, 12μm pixel pitch thermal detector with a focal length up to 35mm/55mm.
- It supports tripwire/intrusion detection.
- It can be used for perimeter protection in critical facilities.
Description
1. 12μm Uncooled Infrared Detector
Adopting the latest 12μm uncooled infrared detectors, integrated with advanced infrared imaging algorithms for better image quality.
2. Intelligent Video Analysis
Support tripwire/intrusion detection, as well as intelligent detection of fire point.
3. Long-Range Detection
Supports 35mm/55mm/75mm fixed-focus infrared lenses to meet long-range detection needs.
4. Platform Integration
Support ONVIF, provide SDK and DEMO for development; provide NVR and VMS software for application.
Specifications
| Category | Specifications |
|---|---|
| Thermal Module | |
| Detector Type | VOx detectors, uncooled FPA |
| Spectral Range | 8 ~ 14 μm |
| NETD (GRID) | ≤40 mK (@25 °C, F#1.0, 25 Hz) |
| Resolution | 640 × 512 |
| Pixel Pitch | 12 μm |
| Focal Length | 35 mm / 55 mm |
| Smart Function | |
| Fire Detection | Support |
| ACV | Line crossing and intrusion detection |
| Two-Way Audio | Support |
| Linking Action | Video/Snapshot/Email/Alarm output/Sound and light alarm |
| System Interface | |
| Power | DC 12V ±25% / POE (802.3at) |
| Network | 1 RJ45 10M / 100M self-adaptive Ethernet port |
| Audio | 1 input / 1 output |
| Storage | Micro SD memory (maximum 256G) |
| Reboot | Support |
| Serial Port | 1 RS485 channel, compatible with Pelco protocol |
| Analogous Thing | 1 BNC connector |
| General | |
| Work Environment | -40℃~+70℃; <95%RH |
| Protection | IP66 |
| Energy Consumption | ≤4 W |
| Dimension (mm) | 334.7 × 121.5 × 104.4 |
| Weight | ≤1.5 kg |
Applications
Border and Coastal Surveillance
Urban High-Altitude Surveillance
Critical Infrastructure Protection
River Monitoring
