ATR31 Motorized Focusing Thermal Camera
Views: 550
$0.00
- ATR31 is a high-performance and high-precision electrically adjustable temperature measurement thermal imager that uses a uncooled focal plane detector and offers multiple lens options.
- Supporting multiple protocols such as RTSP and ONVIF, equipped with professional application software and universal SDK development package.
- It is ideal choices for fields such as electronic circuits, education and research, and industrial automation.
Description
High-quality image output
ATR31 can accurately transmit on-site temperature data. Its electric focusing lens design enables the observations of multiple depth-of-field targets using the same lens, thus providing more accurate temperature measurements.
The device can output high-quality infrared images with a resolution of 384×288, supporting rapid temperature data analysis and determination.
High-speed Frame Rate and Real-time Data Transmission
With an image and temperature frame rate of up to 50Hz, ATR31 can capture temperature changes at a very high speed. It is very suitable for applications requiring real-time monitoring of temperature changes. Equipped with a Gigabit network interface, the device also supports real-time transmission of on-site status temperature data, allowing for image monitoring and temperature data analysis at anytime.
Wide measurement range and temperature compensation algorithm
With a wide measurement range from -20°C to +550°C, ATR31 is suitable for industrial scenarios with various high-temperature requirements. The device utilizes a temperature compensation algorithm to adjust for environmental factors and ensure measurement accuracy and reliability.
Specifications
| Category | Specifications |
|---|---|
| Thermal Imaging Parameters |
|
| Detector | Uncooled VOx detector |
| Infrared Resolution | 384×288 |
| Pixel Pitch | 17μm |
| Spectral Band | 8μm~14μm |
| Thermal Sensitivity (NETD) | 50mK |
| Temperature Measurement Function | |
| Measurement Range | -20℃~+150℃, 0℃~550℃ |
| Measurement Accuracy | ±2°C or ±2% of readings, whichever is greater |
| Temperature Measurement Correction | Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance |
| Measurement Tool | 12 points, lines, and areas; supports isotherm setting |
| Temperature Width Stretch | Supports temperature width stretch |
| Image and Video | |
| Frame Rate | 50Hz |
| Palettes | 18 color palettes including black-hot, white-hot, iron red, rainbow, etc. |
| Video Standards | H.264, H.265 |
| Thermal Image Capture | Supports thermal image capture and secondary analysis |
| Mirror Image | Horizontal/Vertical/Diagonal |
| Digital Zoom | 1.0~8.0 continuous zoom (step size: 0.1) |
| System Interface | |
| Communication Interface | RJ45, supporting Gigabit network and customized RS485 for Pecol-D protocol |
| Video Interface | 1-channel analog video |
| Alarm Interface | 1-channel alarm output (optional) |
| Network Protocol | TCP, UDP, ICMP, DHCP, RTSP |
| Interface Protocol | ONVIF, GB28181 |
| Device Specifications | |
| Operating Temperature | -20℃~+60℃ |
| Power Supply Mode | 10~36V DC, POE |
| Typical Power Consumption | 3W |
| Dimensions | 55mm×55mm×110mm |
| Weight | About 430g |
Applications
Education and Research
Industrial Manufacturing
Machine Vision
Power Monitoring
